High Performance Ac And Dc Power Supply 12V 16.5A For Led Light , OLP Protection

Name: High Performance Ac And Dc Power Supply 12V 16.5A For Led Light , OLP Protection
Brand: Anenerge
SKU: AE-SPS200
Rating: 4.7 (146 reviews)

All Products

Waterproof transformer
(55)

AC DC Power Adapter
(91)

LED Modules for Sign Box
(14)

LED Aluminum Profile
(32)

Flexible LED Strip Lights
(12)

AC DC Switching Power Supply
(11)

Constant Voltage LED Driver
(11)

Laptop AC Adapter
(30)

LED Flood Lights
(24)

Certification

Customer Reviews

Sehr engagierter Mitarbeiter seines Unternehmens, Herr Owen Qi informiert seine Kunden zeitnah über alle Produkte seines Unternehmens.

—— Mr. John Goddard

We like Miss Susie service very much, products quality and leading time i also like,have a long term cooperation with Anenerge company.

—— Ms.Aimee Tan

Me gusta Mr.Owen profesional, la calidad COB downlight es agradable, nos guste trabajo muy much.Good,

—— Mr.Martin Suchanek

I'm Online Chat Now

High Performance Ac And Dc Power Supply 12V 16.5A For Led Light , OLP Protection

Large Image : High Performance Ac And Dc Power Supply 12V 16.5A For Led Light , OLP Protection

Product Details:

Place of Origin:	Shenzhen
Brand Name:	Anenerge
Certification:	CE Rohs FCC
Model Number:	AE-SPS200

Payment & Shipping Terms:

Minimum Order Quantity:	500pcs
Price:	negotiation
Packaging Details:	100pcs/CTN
Delivery Time:	3-5 days
Payment Terms:	T/T, Western Union, L/C, MoneyGram
Supply Ability:	10000pcs per month

Contact Now

High Performance Ac And Dc Power Supply 12V 16.5A For Led Light , OLP Protection

Description

Name:	200W Switching Power Supply	Material:	Aluminum
Input:	AC 110V-220V, 50/60HZ	Certificate:	CE,Rohs,FCC
Used:	LED Lights	Packaging:	White Box + Carton
Warranty:	1 Year	Output Protection:	OLP/OVP/SCP
Highlight:	ac and dc power supply , switching power supply adapter

200W Switching Power Supply AC/DC 12V 16.5A Power Supply CE Rohs FCC

Features:

• AC input range selectable by switch

• Protections:Short circuit/Over load/Over voltage

• Cooling by free air convection

• 100% full load burn-in test

• Fixed switching frequency at 83KHz

• 1 year warranty

Advantages:

1. Certificate: CE,Rohs,FCC

2. Quick delievery: 15 days

3. 3 years warranty

4. Quality control: we test one by one before sending out.

5. Long standby time, long lifespan

6. Larger order can get big discount

7. OEM, ODM are highly welcome

Specification

Model		AE-SPS200-5	AE-SPS200-7.5	AE-SPS200-12	AE-SPS200-13.5	AE-SPS200-15	AE-SPS200-24	AE-SPS200-27	AE-SPS200-48
Output	DC Voltage	5V	7.5V	12V	13.5V	15V	24V	27V	48V
	Rated Current	40A	26.5A	16.5A	14.7A	13A	8.3A	7.4A	4.2A
	Current Range	0 ~ 40A	0 ~ 26.5A	0 ~ 16.5A	0 ~ 14.7A	0 ~ 13A	0 ~ 8.3A	0 ~ 7.4A	0 ~ 4.2A
	Rated Power	200W	198.75W	198W	198.45W	198W	199.2W	199.8W	201.6W
	Ripple & Noise (max.)	150mVp-p	150mVp-p	150mVp-p	150mVp-p	150mVp-p	150mVp-p	200mVp-p	240mVp-p
	Voltage Adj. Range	4.5 ~ 5.6V	6~9V	10~13V	12 ~ 15V	13.5~18V	20~26.4V	26 ~ 32V	41 ~ 56V
	Voltage Tolerance	±2.0%	±2.0%	±1.0%	±1.0%	±1.0%	±1.0%	±1.0%	±1.0%
	Line Regulation	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%
	Load Regulation	±1.0%	±1.0%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%
	Setup,Rise, Hold time	200ms, 100ms, 20ms at full load
Input	Voltage Range	90 ~ 132VAC / 180 ~ 264VAC by switch 254 ~ 370VDC
	Frequency Range	47~63HZ
	Efficiency(Typ.)	74%	79%	80%	80%	81%	83%	83%	84%
	AC Current	4.5A/115VAC 2.5A/230VAC
	Inrush Current (max.)	50A/115VAC 50A/230VAC
	Leakage Current	<3.5mA / 240VAC
Protection	Over Load	105 ~ 135% rated output power
	Over Load	Protection type : Hiccup mode, recovers automatically after fault condition is removed
	Over Voltage	5.75 ~ 6.75V	9.4 ~ 10.9V	13.8V~16.2V	15.53 ~ 18.2V	18V~21V	27.6V~32.4V	33.7 ~ 39.2V	57.6 ~ 67.2V
	Over Voltage	Protection type : Shut down o/p voltage, re-power on to recover
	OVER TEMPERATURE	≥90°c (RTH3) Detect on inside ambient temperature
	OVER TEMPERATURE	Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
Environment	Working Temperature	-10 ~ +50°c (Refer to output load derating curve)
	Working Humidity	20~90% RH Non-condensing
	Storage temp.& humidity	-20~+85°C, 10~95%RH
	Temp. coefficient	±0.03%/°C (0~50°C)
	Vibration	10 ~ 500Hz, 2G 10min./1 cycle,60min.each along X,Y,Z axes
Safety & EMC	Safety Standards	Design refer to UL1950
	Withstand Voltage	I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
	Isolation Resistance	I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
	EMI Conduction & Radiation	Design refer to FCC Part15 J Conduction Class A
Others	MTBF	271.9K hrs min. MIL-HDBK-217F (25 °c )
	Dimension	21511550mm (LWH)
	Packing	0.93Kg; 12pcs/12Kg/0.92CUFT
Note	1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°c of ambient temperature.
	2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
	3. Tolerance : includes set up tolerance, line regulation and load regulation.
