Product Details:
|
| Plugs: | EU Plug | Output: | 12v 2a 24w 30w |
|---|---|---|---|
| Color: | Black White | Packaging: | White Box |
| Usage: | Webcam Router Led Strips | Warranty: | 24 Months |
| High Light: | ac dc switching adapter,ac dc portable power adapter |
||
EU ac/dc adapter,12v 1a 2a 2.5a wall mount adapter for LED strips,webcam,router,customized Dc connector
Quick Details
Place of Origin: Guangdong, China (Mainland)
Brand Name: OEM/ Anenerge
Model Number: AE-12002000
Output Type: AC to DC power adapter
Connection: Plug In
color: black or white
advantage: meet china standards
output power (max): 12W/24W/30W
efficiency (max): 85%
inside: built EMC/EMI filter
MOQ: 1000pcs
Usage: CCTV camera,Portable DVD
DC cable: 1.2m
| Usage |
* LED strip ,LED light ,LED table lamp. * Router,amplifier,CCTV camera, * Home appliances ,setup box ,speaker, * Audio & Video equipments, * Wireless communication electronics . * Medical equipments * Ipad, Tablet PC etc ,Notebook |
| DC Output Voltage | 12V± 5% |
| DC Output Current | 2000mA |
| DC Output Power | 24w |
| Working Efficency | 83% |
| Adapter Size | 85*39*31mm (L/W/H) |
| Efficiency | level 5 |
| Warranty | 2 years |
| Certificates approved | TUV CB CE GS ROHS UL/CUL FCC IECS SAA C-tick |
| Input Rated Voltage | 86Vac~264Vac |
| Input Frequency Range | 47Hz~63Hz |
| Safety protection | output voltage protection (120%-150% rated output current) |
| output current protection (150%-180% rated output current) | |
| short current protection | |
| Ripple and Noise | less than 60Mv at full road with 20MHz bandwidth |
| DC connector | 5.5*2.1*11mm (optional) |
| DC cable | 1.5m 2464UL 20AWG cable (optional) |
| Operating Temperature | 0°C - +55°C |
| Storage Temperature | -20°C - +85°C |
| Safety Standard | EN60950 EN60601 ESD (EN61000 3-3) |
| CAS (60950 ITE/TE,EN60601 Medical) FCC Part 15 subpart B Class 2 | |
| AN/NZS CISPR 22:2006 | |
| Turn On Delay Time | less than 3S (AC:110V and full load) |
| Dielectric Voltage | A IEC320 three pin input---output(FG)3000Vac one minute |
| Input Current | less than 0.5A |
| Input Inrush Current | less than 50A |
| Leakage Current | less than 5mA |
| Standby power | less than 0.3w |
| Net Weight | 156g/pcs |
| Gross Weight | 13.2kg/carton |
| Carton Box Size | 39*31*29cm |
